AVENTICS R480627296 | ITS ISO 15552 Pneumatic Cylinder | 160 mm Bore, 50 mm Stroke, G 3/4
Need a 160 mm bore over a 50 mm stroke? The AVENTICS R480627296 is a double-acting ITS pneumatic cylinder built to ISO 15552. Rated to 10 bar, this 50 mm stroke version uses pneumatic cushioning.
- Stroke 50 mm / bore 160 mm, double action
- Uses pneumatic cushioning at 160 mm bore, 50 mm stroke
- Maximum operating pressure 10 bar (160 x 50 mm)
- R480627296 piston rod thread: male
- Connection thread G 3/4, 50 mm stroke variant
- -20 °C to +80 °C temperature range for the R480627296
- Detailed Description
- Specifications
- Downloads
Built with external thread piston rod for enhanced connectivity
Manufactured with a combination of stainless steel and durable aluminum materials
Provides magnetic sensing for high-precision actuation
Demonstrates a wide operating temperature range for diverse environments
Features adjustable cushioning length for tailored performance
Includes ATEX certification for safe operation in hazardous areas
Compatible with multiple clamping pieces for sensor integration
Robust design incorporates a high-quality scraper for improved longevity
| Brand | AVENTICS |
| Manufacturer Series | ITS |
| Model Number P | R480627296 |
| Action | Double |
| Bore | 160 mm (6.30 in) |
| Stroke | 50 mm (1.97 in) |
| Pneumatic Connection | G 3/4 |
| Port Connection | G 3/4 |
| Cushioning Type | Pneumatic Cushioning |
| Maximum Operating Pressure | 10 bar (145 psi) |
| Maximum Operating Temperature | +80 °C (176 °F) |
| Minimum Operating Temperature | -20 °C (-4 °F) |
| Piston Rod Thread Gender | Male |
| ISO Standard | 15552 |
