Chicago Pneumatic CP3019-25ES | Angle Die Grinder | 1/4 in collet, 25,000 rpm, 375 W
Rated at 375 W and 25,000 rpm, the Chicago Pneumatic CP3019-25ES angle die grinder takes a 1/4 in (6.35 mm) collet. The CP3019-25ES measures 249 mm overall and weighs 0.57 kg.
- Compact industrial angle die grinder; 249 mm overall length
- Up to 2,000 hours between maintenance intervals in demanding applications; 0.57 kg net weight
- Ergonomic design aimed at productive work; 9 l/s air use under load
- 1/4 in air inlet, minimum hose size 8 mm and 9 l/s air consumption under load; sound pressure 76.9 dB(A)
- Declared vibration 3.2 m/s², sound pressure 76.9 dB(A) and sound power 87.9 dB(A)
- Specifications
- Features
| Part Number | CP3019-25ES |
| Brand | Chicago Pneumatic |
| Product Number | 6151602180 |
| Free speed | 25,000 rpm |
| Power | 375 W |
| Collet size | 1/4 in (6.35 mm) |
| Air inlet thread | 1/4 in |
| Air consumption (under load) | 9 l/s |
| Min. hose size | 8 mm |
| Length | 249 mm |
| Net weight | 0.57 kg |
| Vibration | 3.2 m/s² |
| Sound pressure | 76.9 dB(A) |
| Sound power | 87.9 dB(A) |
- Compact body
- Insulating composite over-housing
- Streamlined safety lever
- Rear exhaust
- 1/4" (6.35 mm) collet holder
- Extended body
- 0.5 hp (375 W) governed motor
- 25,000 rpm free speed
