Compact speed monitor ifm electronic DI5009 - DIA3010-ZPKG/US-100-DPS

Name: Compact speed monitor ifm electronic DI5009 - DIA3010-ZPKG/US-100-DPS
Brand: ifm
SKU: DI5009 - DIA3010-ZPKG/US-100-DPS
Availability: OutOfStock

Part Number : DI5009 - DIA3010-ZPKG/US-100-DPS

The compact speed monitor DI5009 - DIA3010-ZPKG/US-100-DPS from ifm electronic is a flush mountable inductive sensor with 10 mm sensing range and integrated speed evaluation. The speed limit can be set via potentiometer in a range of 5-300 pulses/min. The M30 speed monitor DI5009 operates with a supply voltage of 10-36 V DC and is connected via a M12 connector.

Availability: Sold out

Specifications
Features
Downloads

Application	simple evaluation of rotating and linear movement with regard to underspeed; blocking
Current consumption [mA]	<15
Electrical design	PNP
Housing	Threaded type
Output function	normally open
Overload protection	yes
Protection	IP 67
Reverse polarity protection	yes
System	gold-plated contacts

Reliable non-contact monitoring of the rotational speed with regard to underspeed
2 in 1: speed sensor and evaluation in one compact housing
Easy setting of the switch point via potentiometer
For direct connection to a PLC
Reduced installation complexity
