CONCOA 5338053-01-001 | 533 Series High Flow Diaphragm Valve | 1/2 in FNPT x 1/2 in Tube Stub, 0.30 Cv
Part Number : 5338053-01-001
Part 5338053-01-001 from CONCOA pairs 1/2 in FNPT x 1/2 in tube stub inlet/outlet connections with a 0.30 Cv rating. Valve 5338053-01-001 accepts inlet pressure up to 3500 PSIG (240 BAR), matching its maximum differential back pressure. Typical duty for 5338053-01-001 is primary or pipeline control in specialty and high flow gas systems.
Key features
- PCTFE seat gives valve 5338053-01-001 positive shut-off
- Valve 5338053-01-001: helium leak integrity 2 x 10⁻⁸
- Cleanroom assembled; cleanliness of valve 5338053-01-001 meets or exceeds CGA G-4.1
- Valve 5338053-01-001 uses a forged 316L stainless steel body
For pricing, please contact our experts.
