CONCOA 8066686-01-1 | 6600 Series Cylinder Regulator | Oxygen, CGA 540, 250 PSIG Delivery
Part Number : 8066686-01-1
CONCOA 8066686-01-1 is the oxygen cylinder regulator of the 6600 Series Cylinder Regulator line, fitted with a CGA 540 cylinder inlet and a 1/4 in MNPT outlet. Maximum delivery pressure is 250 PSIG (17 BAR), inlet pressure is rated to 3000 PSIG (210 BAR) and the seat is PTFE. Gauges fitted to 8066686-01-1 read 0-400 PSIG/0-2800 kPa and 0-4000 PSIG/0-28,000 kPa.
Key features
- A Cv of 0.2 with a CAPSULE® seat design for easy maintenance
- Cleanliness that meets or exceeds CGA G-4.1 with a forged brass body and bonnet
- CRN OH5216.5R2 registration and a heavy-duty machined brass bonnet
- Steady control from a chloroprene diaphragm with medium-large seat displacement for high flow capacity
For pricing, please contact our experts.
