Dakota A-000-9002 | Magnetic Spring Loaded Centre Pin Fixture | 1/8 in, Hex Head Bolts

Name: Dakota A-000-9002 | Magnetic Spring Loaded Centre Pin Fixture | 1/8 in, Hex Head Bolts
Brand: Dakota Ultrasonics
SKU: A-000-9002
Availability: InStock

Part Number : A-000-9002

Dakota A-000-9002 is a 1/8 in magnetic spring loaded centre pin fixture for hex head bolts. Dakota lists it with its transducer cables and adaptors. The magnetic body holds the fixture on the bolt head while the spring loaded centre pin makes contact, giving a steady connection point during ultrasonic measurement.

Key features

Size: 1/8 in
Magnetic, spring loaded centre pin
For hex head bolts

Availability: in stock

Specifications

Part Number	A-000-9002
Brand	Dakota Ultrasonics
Size	1/8 in
Type	Magnetic spring loaded centre pin fixture
Application	Hex head bolts
Description	1/8 in Magnetic Spring Loaded Center Pin Fixture – Hex Head Bolts
