Dakota X-752-0000 | Acrylic Pencil Delay Line Tip | 1/8 in x .450

Name: Dakota X-752-0000 | Acrylic Pencil Delay Line Tip | 1/8 in x .450
Brand: Dakota Ultrasonics
SKU: X-752-0000
Availability: InStock

Part Number : X-752-0000

Part number X-752-0000 is Dakota's 1/8 in dia x 0.45 in long pencil delay line tip made from acrylic. By slowing the sound pulse from a single element transducer, the tip makes accurate measurement of thinner sections possible. Being acrylic, it is the type to use on steel, aluminium and titanium in interface-echo or echo-echo mode.

Key features

Size: 1/8 in dia x 0.45 in long
Material: Acrylic
Type: Delay Line Tip (Pencil)

Availability: in stock

Specifications

Part Number	X-752-0000
Brand	Dakota Ultrasonics
Size	1/8 in x .450
Dimensions	1/8 in dia x 0.45 in long
Type	Delay Line Tip (Pencil)
Material	Acrylic
