Dwyer 1230-12-D | Wall Mount Well-Type Manometer | 0-12" w.c., Red Gage Oil
Part Number : 1230-12-D
The Dwyer 1230-12-D is a Series 1230 Flex-Tube wall mount well-type manometer with a 0-12 in w.c. range, using red gage oil as its fluid. This single-column 1230-12-D reads positive, negative or differential pressure directly.
- 1230-12-D range 0-12 in w.c.; maximum operating pressure 12 in H2O
- Indicating fluid for the 1230-12-D: red gage oil
- 1230-12-D is rated to 100 psig (6.89 bar); vacuum service beyond 5 in Hg (68 in w.c.) is not advised
- Over-pressure safety traps on the 1230-12-D prevent fluid loss
- Machined solid acrylic well with cemented, leak-resistant joints; no packing glands or hidden wells (1230-12-D)
- Fast-acting positive scale adjustment on the 1230-12-D
Free UAE shipping available
For pricing, please contact our experts.
