Dwyer 1230-16-D | Wall Mount Well-Type Manometer | 0-16" w.c., Red Gage Oil
Part Number : 1230-16-D
Dwyer 1230-16-D: 0-16 in w.c., red gage oil fill, in a Series 1230 wall mount well-type format. The 1230-16-D is a direct-reading, single-column manometer for positive, negative or differential pressure.
- 1230-16-D range 0-16 in w.c.; maximum operating pressure 16 in H2O
- Indicating fluid for the 1230-16-D: red gage oil
- Rated 100 psig (6.89 bar), with vacuum use not advised above 5 in Hg (68 in w.c.) on the 1230-16-D
- Fluid loss on the 1230-16-D is prevented by over-pressure safety traps
- Clear plastic tubing on the 1230-16-D is cemented to a precision-machined acrylic well assembly
- Positive, fast-acting scale adjuster (1230-16-D)
