Dwyer 165EL-SS | PRECISOR II Positioner | 4-20 mA input, stainless steel
Part Number : 165EL-SS
The Dwyer 165EL-SS is the stainless steel enclosure version of the PRECISOR II electro-pneumatic positioner, driven by a 4-20 mA DC signal over a 10 to 150 mm stroke. It suits sectors such as pulp and paper, food and beverage, pharmaceutical and chemical processing.
- 165EL-SS accuracy figures: linearity ±0.2% FS, repeatability ±0.5% FS, hysteresis 1% FS
- 165EL-SS air supply 20-100 psig (1.4-6.9 bar), consumption 0.10 scfm at 20 psig
- Flow capacity of the 165EL-SS: 28 scfm (80 LPM) at 20 psig supply
- 165EL-SS enclosure rated IP66 (NEMA 4X)
- 165EL-SS ports: 1/4" NPT air supply, 1/8" NPT gauge, 1/2" NPT conduit
