Name: Dwyer 3MSV-BF120 | Ball Valve | Type: 1/8" Female NPT
Brand: Dwyer
SKU: 3MSV-BF120
Availability: InStock

Part Number : 3MSV-BF120

The Dwyer 3MSV-BF120 is a ball valve with connection Type: 1/8" Female NPT, body Valve: Brass and inlet Size: 1/8".

Availability: low stock

Free UAE shipping available

Type	Compact 3-Way Ball Valve
Connection	Type: 1/8" Female NPT
Maximum Operating Pressure	1500 psig (103 bar)
Material	Wetted: Body, Connector: 316 SS or Brass Stem, Ball: 316 SS Stem O-ring, Connector O-ring, Back-up Rings: Fluoroelastomer Ball Seats: PTFE
Maximum Operating Temperature	-40 to 350 °F (-40 to 176 °C)
Manufacturer	Dwyer Instruments
Body	Valve: Brass
Inlet	Size: 1/8"
Orifice	0.125 (3.18) in (mm)
Outlet	Size: 1/8"

The Series 3MSV Compact 3-Way Ball Valves are designed for precise directional control of fluid in instrumentation and process systems, offering versatile fluid routing options.
With a micro-finished ball and PTFE seats, these valves ensure a quality seal and easy operation, reducing the risk of leakage and simplifying maintenance.
Their straight-through flow path design allows for minimal pressure drop, ensuring efficient fluid flow and system performance.
Available in either brass or 316 stainless steel, the valve body offers a variety of options to suit different environmental and application requirements.
The valves feature a blow-out-proof ball and stem design, providing extra durability and safety by preventing failure in the event of overpressure scenarios.
