Dwyer 607-9 | Differential Pressure Transmitter | 0-25 in w.c., 607 Series
The Dwyer 607-9 is a Series 607 differential pressure transmitter with a 0-25 in w.c. range, for use with air and other compatible gases. The series is offered with ±0.25% or ±0.5% accuracy for demanding low-range work.
- Range of the 607-9: 0-25 in w.c.
- Ultra-thin silicon diaphragm with glass cladding, which virtually eliminates drift and resists shock and vibration
- NIST standard certification supplied with every unit
- NEMA 2 stainless steel housing resists moisture and dirt
- 3/16 in (0.1875 in) port size
- Specifications
- Features
- Downloads
| Part Number | 607-9 |
| Brand | Dwyer |
| Range | 0-25 in w.c. |
| Series | 607 |
| Series Accuracy Options | ±0.25% or ±0.5% |
| Sensor | Silicon diaphragm, glass clad |
| Housing | Stainless steel, NEMA 2 |
| Port Size | 0.1875 in |
| Operating Fluid | Air, non-combustible gas, non-corrosive gas |
| Certification | NIST certificate |
- Excellent accuracy is made possible by high stability at low pressure ranges, which helps to maintain tight control and reduce expensive out-of-specification situations.
- sensitivity to pressure changes while avoiding vibration and drift, resulting in more precise readings.
- Clean room and laboratory application regulations are met by the stainless steel housing.
