Dwyer Instruments AVUL-5DA1-LCD | Air velocity transmitter | 5% of reading accuracy | Duct mount | Universal current/voltage outputs | with LCD
A high-velocity duct-mount air velocity transmitter designed for supply and exhaust duct applications, offering 5% of reading accuracy, universal current/voltage analog outputs, and field-selectable velocity ranges from 1000 to 4000 FPM (5–20 m/s). The onboard 5-digit LCD allows technicians to verify readings locally during installation and commissioning.
Request a quote in under a minute — call +971 6 5436933.
Part Number-AVUL-5DA1-LCD
The Dwyer AVUL-5DA1-LCD is designed for higher-velocity supply and exhaust duct applications where reliable air velocity measurement and flexible analog integration are required. It measures air velocity from 1000 to 4000 FPM (5–20 m/s) with 5% of reading accuracy and provides universal current/voltage analog outputs for connection to building automation and control systems.
The transmitter features a NEMA 4X (IP66) enclosure, making it suitable for mechanical rooms, plenums, and other demanding HVAC environments. It operates across 32–122°F (0–50°C) and tolerates 5–95% RH non-condensing conditions.
With a response time of approximately 4 seconds, or approximately 1 second at constant temperature, the AVUL-5DA1-LCD is suitable for real-time AHU and fan-control applications. It operates on 24 VDC or 24 VAC, with a maximum current requirement of 60 mA, simplifying installation for both retrofit and new HVAC control projects.
A built-in 5-digit LCD provides convenient local readouts during commissioning and troubleshooting. The compact transmitter mounts into a standard duct probe assembly and carries BTL and CE approvals.
For applications requiring the same high-velocity measurement range without a local display, the AVUL-5DA1 is the corresponding non-LCD model.
Key Benefits
- 5% of reading accuracy for higher-velocity duct applications
- Universal current/voltage analog outputs for direct BMS integration
- Field-selectable velocity ranges of 1000, 2000, 3000, or 4000 FPM
- Equivalent metric ranges of 5, 10, 15, or 20 m/s
- NEMA 4X (IP66) enclosure for demanding HVAC environments
- Built-in 5-digit LCD for local commissioning and verification
- 24 VDC or 24 VAC power supply
- Suitable for AHU, fan-control, supply-air, and exhaust-air applications
- BTL and CE approved
Who This Product Is Best For
The Dwyer AVUL-5DA1-LCD is suitable for HVAC controls contractors, BMS integrators, building automation professionals, and facility maintenance teams working with higher-velocity duct systems.
It is particularly useful where technicians need both flexible analog output integration and a local display for commissioning, troubleshooting, and on-site verification.
How to Use
- Mount the AVUL-5DA1-LCD in the duct using standard probe insertion practices.
- Connect 24 VDC or 24 VAC power according to the installation requirements.
- Connect the universal current/voltage analog output to the BMS, controller, or compatible monitoring system.
- Select the required velocity range: 1000, 2000, 3000, or 4000 FPM.
- Verify the air velocity reading on the 5-digit LCD during commissioning.
- Confirm that the transmitter output is correctly recognized by the connected control system.
Frequently Asked Questions
What accuracy does the AVUL-5DA1-LCD provide?
The transmitter provides 5% of reading accuracy across its field-selectable velocity ranges.
What velocity ranges can the AVUL-5DA1-LCD measure?
The velocity range can be selected between 1000, 2000, 3000, and 4000 FPM, equivalent to 5, 10, 15, and 20 m/s.
What outputs does the AVUL-5DA1-LCD provide?
It provides universal current/voltage analog outputs, including 4–20 mA, 0–5 VDC, and 0–10 VDC, making it suitable for compatible HVAC controllers and BMS applications.
What is the enclosure rating?
The AVUL-5DA1-LCD has a NEMA 4X (IP66) enclosure rating.
Does the AVUL-5DA1-LCD have a local display?
Yes. It includes a 5-digit LCD that allows technicians to view measurements locally during installation, commissioning, and troubleshooting.
What power supply does the transmitter require?
The AVUL-5DA1-LCD operates on 24 VDC or 24 VAC and has a maximum current requirement of 60 mA.
Is there a non-LCD version available?
Yes. The Dwyer AVUL-5DA1 provides the same high-velocity application range without the onboard LCD display.
Does GeneralTech Shop deliver the AVUL-5DA1-LCD across the UAE?
Yes. Contact GeneralTech Shop at +971 6 5436933 to confirm pricing and delivery availability for your emirate.
