Dwyer Instruments BCHP-KIT | Bench Top Calibration Pump Kit;Includes Pump;Case;and Fine Adjustment Tool
The Dwyer BCHP-KIT calibration pump kit combines the Series BCHP bench top calibration pump with a carrying case and fine volume adjustment tool for a complete, transportable pressure and vacuum calibration solution. The pump generates from -28 in. Hg vacuum to 870 psi (60 bar) and features dual pressure ports for connecting two instruments simultaneously.
Genuine Control Techniques stock · Free UAE-wide shipping
Part Number: BCHP-KIT
Request a quote in under a minute — call +971 6 5436933.
Product Overview
The Dwyer BCHP-KIT is a complete bench top calibration solution for generating both pressure and vacuum when testing or calibrating pressure gauges, transmitters, switches, and similar instruments.
The pump covers a wide range from -28 in. Hg vacuum to 870 psi (60 bar), allowing technicians to perform both vacuum and high-pressure calibration work using a single hand-operated pump.
The dual pressure ports allow a device under test and a reference gauge or calibration standard to be connected simultaneously without requiring additional fittings. This makes it convenient for direct comparison during calibration.
What distinguishes the BCHP-KIT from the standard BCHP-1 configuration is the inclusion of a carrying case and fine volume adjustment tool. The additional accessories make the kit easier to transport between calibration locations and provide additional control when establishing precise test points.
The pump is supplied with 1/4" NPT fittings and uses air as the pressure medium. Its construction combines anodized aluminum, brass, and ABS for a robust design suitable for regular calibration work.
The BCHP-KIT is suitable for both field calibration and fixed laboratory or production-floor applications, particularly where portability and a wide pressure range are important.
Key Benefits
- Complete calibration kit with pump, carrying case, and fine volume adjustment tool
- Generates vacuum and pressure from -28 in. Hg to 870 psi (60 bar)
- Dual pressure ports allow two instruments to be connected simultaneously
- 1/4" NPT fittings supplied with the pump
- Fine adjustment valve and tool help establish precise test points
- Carrying case provides convenient transport between work locations
- Suitable for field technicians, calibration laboratories, and production areas
- Suitable for high-pressure calibration work up to 870 psi
- Robust anodized aluminum, brass, and ABS construction
- Genuine Dwyer stock with free UAE-wide shipping
Who This Product Is Best For
The Dwyer BCHP-KIT is suited to field calibration technicians, maintenance engineers, calibration laboratories, and production teams that require a portable pressure and vacuum calibration solution.
It is particularly useful when technicians need to transport the calibration pump between sites or when a complete kit with the required accessories is preferred over purchasing the pump alone.
How to Use
- Unpack the BCHP-KIT, including the pump, carrying case, and fine volume adjustment tool.
- Connect the device under test to one of the pump's dual pressure ports using the supplied 1/4" NPT fittings.
- Connect a reference gauge or calibration standard to the second pressure port.
- Operate the pump to generate the required vacuum or pressure.
- Use the fine adjustment valve and adjustment tool to establish and maintain the required test point.
- Compare the device under test with the reference instrument and record the calibration results.
Frequently Asked Questions
What's included in the Dwyer BCHP-KIT?
The kit includes the Series BCHP calibration pump, carrying case, and fine volume adjustment tool. The pump is supplied with 1/4" NPT fittings.
What pressure and vacuum range does the BCHP-KIT cover?
The pump generates from -28 in. Hg vacuum to 870 psi (60 bar).
Can two instruments be connected to the BCHP-KIT at the same time?
Yes. The pump has dual pressure ports, allowing a device under test and reference instrument to be connected simultaneously.
Is the BCHP-KIT suitable for field calibration?
Yes. The included carrying case makes the BCHP-KIT convenient to transport between calibration sites and field service locations.
What is the purpose of the fine volume adjustment tool?
The tool provides additional fine control when adjusting the generated pressure or vacuum to the required calibration point.
What is the difference between the BCHP-KIT and BCHP-1?
The BCHP-KIT includes the same Series BCHP pump together with a carrying case and fine volume adjustment tool. The BCHP-1 is the pump supplied on its own without these additional kit accessories.
What pressure medium does the BCHP-KIT use?
The pump uses air as its pressure medium.
Is genuine BCHP-KIT stock available with UAE shipping?
Yes. Genuine Dwyer stock with free UAE-wide shipping is available. Call +971 6 5436933 for current pricing and availability.
