Dwyer DL72 | Differential Pressure Data Logger | ±2" w.c. (5.0 mbar)
For room pressure checks and duct air velocity monitoring, the Dwyer DL72 records differential pressure across ±2 in w.c. (5.0 mbar) plus temperature, running from its own internal battery. Accuracy on this ±2 in w.c. model is ±0.05 in w.c., with ±0.01 in w.c. resolution.
- Resolves ±0.01" w.c. with ±0.05" w.c. accuracy
- Self-powered by an internal lithium cell; uses Model DL200 software (separate) for programming and data transfer
- Withstands up to 4X rated pressure; stores as many as 21,500 readings
- Specifications
- Features
- Downloads
| Part Number | DL72 |
| Brand | Dwyer |
| Range | ±2" w.c. (5.0 mbar) |
| Accuracy | ±0.05" w.c. |
| Resolution | ±0.01" w.c. |
| Repeatability | ±0.05% FS |
| Drift | ±0.5% FS/yr |
| Channels | 2: differential pressure, internal thermistor |
| Thermistor Range | -40 to 158°F (-40 to 70°C) |
| Memory | 21,500 readings |
| Sampling Rate | 0.04 s to 8 h |
| Connection | Two 1/8" I.D. permanent protective tubing |
| Power | 3.6 V lithium battery, internal |
| Weight | 4 oz (110 g) |
- Use Model DL200 Windows® software (sold separately) to quickly program the logger or upload data to a computer.
- The series DL7 logger is ideal for monitoring air duct velocity, testing and balancing HVAC systems, or verifying room pressure.
