Dwyer DLI2-A13 | LCD Pressure Data Logger | 0-300 psia, 0.02 psi Resolution
With a 0-300 psia range and 0.02 psi resolution, the Dwyer DLI2-A13 logs absolute pressure and can be scheduled from a PC to start up to six months ahead. DL700 software makes graphing and calculations with DLI2-A13 data straightforward.
- 0-300 psia absolute range, 0.02 psi resolution
- IP65 rated; wetted parts in 316L SS
- USB port for DL700 software; cable needed
- Approx. 1 year battery life from 6 AA batteries
- Memory for more than 260,000 readings
- Sample rate 2 s to 12 hrs
- Specifications
- Features
- Downloads
| Part Number | DLI2-A13 |
| Brand | Dwyer |
| Range | 0-300 psia |
| Pressure Type | Absolute |
| Resolution | 0.02 psi |
| Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Memory | 262,143 readings |
| Sampling Rate | 2 s to 12 h |
| Sampling Methods | Stop on memory full or continuous |
| Interface | USB port (interface cable required) |
| Wetted Material | 316L SS |
| Housing | Black anodised aluminium, IP65 |
| Power | 6 x AA alkaline batteries; optional AC adapter |
| Weight | 40 oz (1134 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Easy setup via an intuitive keypad interface enables centralized control over data collection.
