Dwyer DLI2-A14 | LCD Pressure Data Logger | 0-500 psia, 0.05 psi Resolution
The Dwyer DLI2-A14 pressure logger covers 0-500 psia (absolute) and reads out in psi, in Hg, mm Hg, bar, atm, Torr, Pa, kPa or MPa from the keypad or software. The DLI2-A14 can be started and stopped from a PC or scheduled up to six months ahead.
- 0-500 psia absolute range, 0.05 psi resolution
- DL700 software for graphing and records; USB interface cable required; 6 x AA batteries, about 1 year life; optional AC adapter
- 262,143-reading memory; sampling from 2 s to 12 h
- Specifications
- Features
- Downloads
| Part Number | DLI2-A14 |
| Brand | Dwyer |
| Range | 0-500 psia |
| Pressure Type | Absolute |
| Resolution | 0.05 psi |
| Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Memory | 262,143 readings |
| Sampling Rate | 2 s to 12 h |
| Sampling Methods | Stop on memory full or continuous |
| Interface | USB port (interface cable required) |
| Wetted Material | 316L SS |
| Housing | Black anodised aluminium, IP65 |
| Power | 6 x AA alkaline batteries; optional AC adapter |
| Weight | 40 oz (1134 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Easy setup via an intuitive keypad interface enables centralized control over data collection.
