Dwyer DLI2-A19 | LCD Pressure Data Logger | 0-5000 psia, 0.2 psi Resolution
Recording absolute pressure over 0-5000 psia, the Dwyer DLI2-A19 shows live readings, memory and battery status on its backlit LCD, and stores more than 260,000 readings. DL700 software makes graphing and calculations with DLI2-A19 data straightforward.
- 0-5000 psia absolute range, 0.2 psi resolution
- Memory for more than 260,000 readings; sample rate 2 s to 12 hrs
- IP65 rated; wetted parts in 316L SS; USB port for DL700 software; cable needed
- Specifications
- Features
- Downloads
| Part Number | DLI2-A19 |
| Brand | Dwyer |
| Range | 0-5000 psia |
| Pressure Type | Absolute |
| Resolution | 0.2 psi |
| Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Memory | 262,143 readings |
| Sampling Rate | 2 s to 12 h |
| Sampling Methods | Stop on memory full or continuous |
| Interface | USB port (interface cable required) |
| Wetted Material | 316L SS |
| Housing | Black anodised aluminium, IP65 |
| Power | 6 x AA alkaline batteries; optional AC adapter |
| Weight | 40 oz (1134 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Easy setup via an intuitive keypad interface enables centralized control over data collection.
