Dwyer Instruments DLI2-G08 | LCD pressure data logger | Range 0-30 psig
The Model DLI2-G08 LCD Pressure Data Logger provides immediate remote readings and precise pressure recording. Easy access to memory and battery levels, as well as current data and recorder settings, is made possible by the big, backlit LCD and 8-button keypad. Up to 5,000 psi of absolute or gage pressure can be measured with the Series DLI2. Measurements can be read in psi, in. Hg, mm Hg, bar, atm, Torr, Pa, kPa, or MPa using the keypad or software. Its large memory capacity makes it possible to store more than 260,000 readings. Data calculations, data graphing, and permanent record creation are all made simple by the user-friendly DL700 software. It is simple to start and stop the DLI2 from a PC, and it may be scheduled to start up to six months in advance. Additionally, it has the ability to stop recording at a given moment or after a predetermined amount of readings.
- Specifications
- Features
- Downloads
| Accuracy | 2% FSR, 0.25% at 77°F (25°C) typical |
| Approvals | CE |
| Battery Life | 1 yr (approx) |
| Housing Material | Black anodized aluminum case |
| Interface | USB port (interface cable required) |
| IP PROTECTION RATING | IP65 |
| Material | Wetted: 316L SS |
| MEMORY SIZE | 262,143 readings |
| Power | (6) AA alkaline batteries, installed functional, user replaceable. Optional AC adapter |
| Range | 0-30 psig |
| Resolution | 0.002 psi (30 psi), 0.005 psi (100 psi), 0.02 psi (300 psi), 0.05 psi (500 and 1000 psi), and 0.2 psi (5000 psi) depending on model |
| Sampling Methods | Stop on memory full or continuous recording |
| Sampling Rate | Selectable from 2 sec to 12 hrs |
| Weight | 40 oz (1134 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Easy setup via an intuitive keypad interface enables centralized control over data collection.
