Dwyer DLI2-G10 | LCD Pressure Data Logger | 0-100 psig, 0.005 psi Resolution
The Dwyer DLI2-G10 pressure logger covers 0-100 psig (gauge) and reads out in psi, in Hg, mm Hg, bar, atm, Torr, Pa, kPa or MPa from the keypad or software. Recording on the DLI2-G10 can end at a set time or after a chosen number of readings.
- 0-100 psig gauge range, 0.005 psi resolution
- 316L stainless steel wetted parts in an IP65 aluminium case; works with DL700 software via USB (interface cable required)
- Runs about a year on six AA cells, or an optional AC adapter; memory for more than 260,000 readings
- Specifications
- Features
- Downloads
| Part Number | DLI2-G10 |
| Brand | Dwyer |
| Range | 0-100 psig |
| Pressure Type | Gauge |
| Resolution | 0.005 psi |
| Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Memory | 262,143 readings |
| Sampling Rate | 2 s to 12 h |
| Sampling Methods | Stop on memory full or continuous |
| Interface | USB port (interface cable required) |
| Wetted Material | 316L SS |
| Housing | Black anodised aluminium, IP65 |
| Power | 6 x AA alkaline batteries; optional AC adapter |
| Weight | 40 oz (1134 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Easy setup via an intuitive keypad interface enables centralized control over data collection.
