Dwyer DLP-A13 | Pressure/Temperature Data Logger | 0-300 psia, 1/4" NPT
The Dwyer DLP-A13 logs absolute pressure from 0 to 300 psia together with temperature from its built-in sensor, so no separate temperature recorder is needed. A standard 1/4" NPT connection adapts to most pressure fittings.
- 0-300 psia range with built-in temperature sensing
- More than 16,000 readings stored per channel
- Start and stop from a PC, or schedule up to six months ahead
- DL700 software for data retrieval; interface cable sold separately
- Stainless steel body, 12 oz (340 g)
- Specifications
- Features
- Downloads
| Part Number | DLP-A13 |
| Brand | Dwyer |
| Pressure Range | 0-300 psia |
| Pressure Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Temperature Accuracy | ±0.9°F (±0.5°C) |
| Temperature Resolution | 0.2°F (0.1°C) |
| Memory | 16,383 readings per channel |
| Process Connection | 1/4" NPT |
| Material | Stainless steel |
| Sampling Methods | Stop on memory full |
| Power | 3.6 V lithium battery, user replaceable |
| Weight | 12 oz (340 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Battery power eliminates the requirement for hard wiring, making the device useful as a tool for a range of in-and-out tests.
- PC start and stop provide centralized management of data gathering.
