Dwyer DLP-A15 | Pressure/Temperature Data Logger | 0-1000 psia, 1/4" NPT
Covering 0-1000 psia, the Dwyer DLP-A15 is a battery-powered pressure and temperature data logger with a standard 1/4" NPT fitting and an internal temperature sensor. Data is retrieved with DL700 software, and more than 16,000 readings are stored per channel.
- Higher 0-1000 psia absolute pressure range
- Temperature accuracy ±0.9°F (±0.5°C)
- 16,383 readings per channel
- Delayed start up to six months, set from a PC
- Needs a separate DL700 interface cable (not included)
- Specifications
- Features
- Downloads
| Part Number | DLP-A15 |
| Brand | Dwyer |
| Pressure Range | 0-1000 psia |
| Pressure Accuracy | 2% FSR; 0.25% at 77°F (25°C) typical |
| Temperature Accuracy | ±0.9°F (±0.5°C) |
| Temperature Resolution | 0.2°F (0.1°C) |
| Memory | 16,383 readings per channel |
| Process Connection | 1/4" NPT |
| Material | Stainless steel |
| Sampling Methods | Stop on memory full |
| Power | 3.6 V lithium battery, user replaceable |
| Weight | 12 oz (340 g) |
- Effective data collection tool for analyzing alarm and out-of-spec circumstances or verifying that operations are operating as intended.
- Battery power eliminates the requirement for hard wiring, making the device useful as a tool for a range of in-and-out tests.
- PC start and stop provide centralized management of data gathering.
