Dwyer Instruments DTFO-2B-4O | Variable-Area Flowmeter for Oil | Range 0-4 gpm oil | 1/2" NPT | Brass body

Name: Dwyer Instruments DTFO-2B-4O | Variable-Area Flowmeter for Oil | Range 0-4 gpm oil | 1/2" NPT | Brass body
Brand: Dwyer
SKU: DTFO-2B-4O
Availability: OutOfStock

Part Number : DTFO-2B-4O

A cost-effective Variable-Area Flowmeter for Liquids, the Series DTFO, Model DTFO-2B-4O measures oil rates to within ±2% of full-scale accuracy. Strong dependability and the capacity to tolerate system pressures of up to 3000 psig (200 bar) are guaranteed by the sturdy metal construction. suitable for a broad range of applications and offered in 1/4", 1/2", and 1" connectors. includes a calibration for mounting in a horizontal line.

Availability: Sold out

Free UAE shipping available

Specifications
Features
Downloads

Accuracy	+/-2% FS
Connection	1/2"
Manufacturer	Dwyer Instruments
Material	Wetted: > Body: 316 SS or brass Spring: 302SS Range spring: 302 SS Magnet: PTFE-coated Metering cone: Acetal or PTFE Seals: Buna
Maximum Operating Pressure	> DTFO-1B and DTFO-2B: 3000 psig (200 bar) DTFO-3S: 1500 psig (100 bar)
Maximum operating temperature	-40 to 200°F ( -40 to 93°C)
Range	0-4 gpm oil
Repeatability	+/-1% FS
Size	Diameter dial face 2.5" (63.5 mm)
Type	Variable-Area Flowmeter
Weight	5 lb (2.27 kg)

Strong dependability and the capacity to tolerate system pressures of up to 3000 psig (200 bar) are guaranteed by the sturdy metal construction.
Unlike glass tube variable area flowmeters, the shatterproof design ensures a long operational life.
Perform precisely in situations with strong vibration, high temperature, and a high risk of shock.

Dwyer Instruments DTFO-2B-4O | Variable-Area Flowmeter for Oil | Range 0-4 gpm oil | 1/2" NPT | Brass body

DOWNLOAD CATALOG
