Dwyer FT-621 | Correlated Flow Tube | 65 mm, 522 mL/min Water, Glass Float
Dwyer FT-621: a correlated 65 mm flow tube with a black glass float, reading up to 522 mL/min of water. Tubes such as the FT-621 are combined in Series MTF multitube systems for multichannel metering, mixing or monitoring.
- Full-scale capacity of 522 mL/min of water
- Black glass float riding between PTFE float stops (FT-621)
- Correlated accuracy of ±2% FS for the 522 mL/min water tube
- ±0.25% repeatability, 522 mL/min water capacity
- Pressure limit 200 psig (13.8 bar) for this 522 mL/min water tube
- Specifications
- Features
- Downloads
| Part Number | FT-621 |
| Brand | Dwyer |
| Tube Type | Correlated |
| Tube Length | 65 mm |
| Float | Black glass |
| Max Flow (Water) | 522 mL/min |
| Accuracy | ±2% FS at 70°F (21.1°C) and 14.7 psia |
| Flowtube | Borosilicate glass |
| Float Stops | PTFE |
| Repeatability | ±0.25% of scale reading |
| Max Operating Pressure | 200 psig (13.8 bar) |
| Max Operating Temperature | 250°F (121°C) |
| Turn-down Ratio | 10:1; 20:1 with two floats in one meter |
| Scale | 65 mm or 150 mm universal scales with correlation charts |
- Systems can have their functionality and design altered to match the needs of a particular application.
- Ability to hold up to six distinct flow tubes, offering flexibility in flow patterns and capacity to meet diverse requirements.
- The exact control and monitoring of fluid flow rates is made possible by the variable flow capacities that each flow tube can have.
- Perfect for multichannel uses including mixing, metering, or monitoring; offers a complete solution for intricate fluid handling procedures.
- Has a modular architecture that facilitates simple assembly and reconfiguration of the system in response to shifting needs or preferences.
- Ideal for a variety of uses necessitating specialized flow systems, such as research applications, laboratory tests, and industrial operations.
- Built with sturdy materials to guarantee lifespan and dependability under varied working circumstances.
