Dwyer P8-11 | High Pressure Flow Switch | set point 0.25 GPM (.95 LPM), 1500 psi
Part Number : P8-11
Dwyer P8-11 is a high pressure brass flow switch with an actuation set point of 0.25 GPM (.95 LPM), built for high in-line pressures. It is rated to 1500 psi (103.4 bar).
- P8-11 brass housing, PPS composite piston, 316 SS spring
- 3/8" male NPT process connection; P8-11 22 AWG, 24" (61 cm) leads
- SPST, N.O. switch; P8-11 accuracy ±20% of set point
- P8-11 temperature range -20 to 275°F (-28 to 135°C)
- Any mounting position; 100 micron filtration recommended for the P8-11
