Dwyer RHP-3D2E | Duct Humidity/Temperature Transmitter | ±3% RH, 0-10 VDC RH, 1K Ω RTD
Part Number : RHP-3D2E
Dwyer RHP-3D2E is a duct-mount transmitter rated ±3% (20 to 80% RH @ 25°C), providing a 0-10 VDC humidity output plus a passive 1K Ω RTD (DIN 385) temperature output. This Series RHP model, RHP-3D2E, senses humidity with a capacitance polymer element.
- Supply for the 0-10 VDC version: 15-35 VDC or 15-29 VAC on the RHP-3D2E
- 1K Ω RTD temperature sensor: DIN Class B, ±0.3°C @ 0°C (±0.54°F @ 32°F) (RHP-3D2E)
- RHP-3D2E: Measures 0 to 100% RH; drift below 1% RH per year, hysteresis ±1%, response time 15 s
- Duct mount: NEMA 4X (IP66) housing, 1/2" NPS conduit connection, 0.616 lb (0.3 kg) on the RHP-3D2E
- Operating range -40 to 140°F (-40 to 60°C) (RHP-3D2E)
