Dwyer SFI-300SS-1-1/4 | Sight Flow Indicator | 1-1/4" Body, Double Window, Impeller
Part Number : SFI-300SS-1-1/4
Dwyer SFI-300SS-1-1/4: a 1-1/4" sight flow indicator with threaded process connections and a double viewing window with a rotating impeller, for checking flow by eye. For servicing, the SFI-300SS-1-1/4 window can be removed and parts replaced.
- 1-1/4" body measuring 4.375" (111 mm) L x 3.125" (79 mm) D x 2.563" (65 mm) H (SFI-300SS-1-1/4)
- SFI-300SS-1-1/4 weight: 3.0 lb (1.4 kg)
- SFI-300SS-1-1/4 pressure limit 125 psig (8.62 bar); MP models 150 psig (10.34 bar)
- SFI-300SS-1-1/4 temperature limit 200°F (93°C); 120°F (48°C) with W2 option, 170°F (77°C) with I1 option
- Wetted parts for SFI-300SS-1-1/4: tempered glass window, bronze or 316 SS body (series options), Buna-N, fluoroelastomer or PTFE gasket, ABS or 316 SS impeller
Free UAE shipping available
For pricing, please contact our experts.
