Dwyer SVP-1 | Proportioning Solenoid Valve | 0.51 mm Orifice, Cv 0.009, 0-24 VDC

Part Number : SVP-1

The Dwyer SVP-1 is a proportioning solenoid valve with a 0.51 mm orifice and Cv of 0.009, opening in proportion to a 0-24 VDC input. It passes up to 7.4 SCFH (3.5 LPM) of air or 2.0 GPH (125 cc/m) of water and closes tightly when de-energised, for uses such as process control, chemical mixing and laboratory testing.

  • Orifice 0.020" (0.51 mm), Cv factor 0.009
  • Maximum flow: 7.4 SCFH (3.5 LPM) air, 2.0 GPH (125 cc/m) water
  • 0-24 VDC input, 400 mA maximum current, spade-type electrical terminals (SVP-1)
  • Up to 500 psig (34.45 bar) operating and 50 psid (3.45 bar) differential pressure on the 0.51 mm model
  • 316 and 416 stainless steel wetted parts with Viton o-rings; 1/4" compression fittings (SVP-1)
  • Process -40 to 79°C, ambient -40 to 54°C (SVP-1)
Availability: low stock
Free UAE shipping available
For pricing, please contact our experts.
