Dwyer SVP-2 | Proportioning Solenoid Valve | 1.02 mm Orifice, Cv 0.033, 0-24 VDC
With a 1.02 mm orifice (Cv 0.033), the Dwyer SVP-2 proportioning solenoid valve meters flow in proportion to an applied 0-24 VDC signal. Maximum flow is 27.5 SCFH (13 LPM) on air and 6.4 GPH (400 cc/m) on water, with tight normally closed shut-off; stated uses include process control and high-tech manufacturing.
- Orifice 0.040" (1.02 mm), Cv factor 0.033
- Maximum flow: 27.5 SCFH (13 LPM) air, 6.4 GPH (400 cc/m) water
- 0-24 VDC input, 400 mA maximum current, spade-type electrical terminals (SVP-2)
- Up to 500 psig (34.45 bar) operating and 50 psid (3.45 bar) differential pressure on the 1.02 mm model
- 316 and 416 stainless steel wetted parts with Viton o-rings; 1/4" compression fittings (SVP-2)
- Process -40 to 79°C, ambient -40 to 54°C (SVP-2)
- Specifications
- Features
- Downloads
| Part Number | SVP-2 |
| Brand | Dwyer |
| Type | Proportioning solenoid valve, normally closed |
| Wetted Materials | 316 and 416 SS; Viton o-rings |
| Orifice | 0.040" (1.02 mm) |
| Maximum Operating Pressure | 500 psig (34.45 bar) |
| Temperature | Process -40 to 79 °C; ambient -40 to 54 °C |
| Cv Factor | 0.033 |
| Maximum Air Flow | 27.5 SCFH (13 LPM) |
| Maximum Water Flow | 6.4 GPH (400 cc/m) |
| Input Signal | 0-24 VDC |
| Maximum Operating Current | 400 mA |
| Maximum Differential Pressure | 50 psid (3.45 bar) |
| Connections | 1/4" compression fitting; spade-type electrical |
- The Series SVP Proportioning Solenoid Valve uniquely controls or regulates flow in proportion to a variable voltage input, offering precise flow control beyond simple on/off functionality.
- Reacting to a 0-24 VDC input signal, the valve opens in proportion to the voltage applied, ensuring that just the right amount of flow is delivered as needed.
- Compatible with a wide range of gases and liquids, making it suitable for diverse applications including process control, chemical mixing, high-tech manufacturing, and laboratory testing.
- Suitable for even the most demanding applications, highlighting its versatility and adaptability across various industries and settings.
- When de-energized, the valve provides tight shut-off (NC), ensuring safety and preventing leaks or unwanted flow when not in operation.
- Positioned as a low-cost solution, offering high performance and functionality at an affordable price point.
- The valve features a uniquely designed construction, setting it apart from traditional solenoid valves and enhancing its performance capabilities.
