Dwyer Instruments VFA-3-EC | Flowmeter | Range .6-5 SCFH air - generaltechuae

Dwyer VFA-3-EC | Visi-Float Acrylic Flowmeter | 0.6-5 SCFH Air, 2" Scale, 5% FS

Part Number : VFA-3-EC

The Dwyer VFA-3-EC is a Visi-Float acrylic flowmeter with a 0.6-5 SCFH air range, read on a 2" (51 mm) scale and suited to gas and liquid service. The VFA-3-EC mounts vertically and connects through a 1/8" female NPT process port.

  • 5% of full scale accuracy
  • Connects via 1/8" female NPT
  • Up to 100 psig (6.9 bar) at 150 °F (65 °C) without a valve
  • Wetted metal parts in nickel-plated brass as standard, stainless steel optional
  • 4.0 to 4.8 oz (0.11 to 0.14 kg) weight
  • Vertical mounting
Availability: low stock
Free UAE shipping available
For pricing, please contact our experts.
