Dwyer Instruments VFA-3-EC-SS | Flowmeter | Range .6-5 SCFH air - generaltechuae

Dwyer VFA-3-EC-SS | Visi-Float Acrylic Flowmeter | 0.6-5 SCFH Air, 2" Scale, 5% FS

Part Number : VFA-3-EC-SS

Covering 0.6-5 SCFH for air, the Dwyer VFA-3-EC-SS Visi-Float flowmeter combines a clear, precision-machined acrylic body with a 2" (51 mm) scale. Install the VFA-3-EC-SS (0.6-5 SCFH) in a vertical position; its process connection is 1/8" female NPT.

  • Connects via 1/8" female NPT
  • Up to 100 psig (6.9 bar) at 150 °F (65 °C) without a valve
  • Wetted metal parts in nickel-plated brass as standard, stainless steel optional
  • 4.0 to 4.8 oz (0.11 to 0.14 kg) weight
  • Vertical mounting
  • RoHS II (2011/65/EU) compliant
Availability: low stock
Free UAE shipping available
For pricing, please contact our experts.
