Dwyer VFA-34 | Visi-Float Acrylic Flowmeter | 20-200 cc/min Water, 2" Scale, 5% FS

Part Number : VFA-34

Dwyer's VFA-34 measures flow from 20-200 cc/min (water) on a 2" (51 mm) scale, using a transparent acrylic body machined for gas and liquid applications. Install the VFA-34 (20-200 cc/min) in a vertical position; its process connection is 1/8" female NPT.

  • Up to 100 psig (6.9 bar) at 150 °F (65 °C) without a valve
  • Wetted metal parts in nickel-plated brass as standard, stainless steel optional
  • 4.0 to 4.8 oz (0.11 to 0.14 kg) weight
  • Vertical mounting
  • RoHS II (2011/65/EU) compliant
  • Rated accuracy of 5% FS
