Dwyer WM2-B-C-13 | Multi-Jet Water Meter | 40mm brass, 20 m³/h max
Part Number : WM2-B-C-13
The Dwyer WM2-B-C-13 is a 40mm brass multi-jet water meter that mechanically totalises water use; its flow ratings are given in m³/h, with a maximum flow of 20 m³/h and a nominal range of 0.8 to 10 m³/h. The WM2 range behind the WM2-B-C-13 is offered with NPT or BSPT couplings.
- WM2-B-C-13 accuracy: ±2% at nominal flow, ±5% at transitional flow
- Transitional flow on the WM2-B-C-13: 0.2 m³/h
- Maximum operating pressure 232 psi (16 bar), temperature 104°F (40°C) (WM2-B-C-13)
- Wetted materials on the WM2-B-C-13: brass/polyethylene body, brass couplings, measuring chamber of polyethylene, ABS, ferrite and acetal
- Install the WM2-B-C-13 horizontally with the register face up
