HIOKI DT4222 | Digital Multimeter
The Hioki DT4200 Digital Multimeter Series consist of a complete lineup of 9 models ranging from professional to industrial to pocket meters, delivering a super fast response rate and safety features that take electrical testing to a higher level. The DT4222 is a pocket-sized digital multimeter designed specifically for general purpose testing, with ±0.5% DC V accuracy and wide 40 Hz to 1 kHz AC V bandwidth.
- Specifications
- Features
- Downloads
Dimensions (mm) | 72 mm (2.83 in) W ƒ- 149 mm (5.87 in) Hƒ- 38 mm (1.50 in) D,190 g (6.7 oz) (with batteries and holster) |
Frequency (Hz) | AC V measurement: 99.99 Hz (5 Hz or more) to 9.999 kHz, 3 ranges Basic accuracy: +/-0.1 % rdg. +/-2 dgt. |
Power Supply | LR03 alkaline batteries ƒ-1, Continuous use: 40 hours (back light OFF) |
Resistance range | 600.0 © to 60.00 M©, 6 ranges, Basic accuracy: +/-0.9 % rdg. +/-5 dgt. |
Voltage | AC- 6.000 V to 600.0 V, 3 ranges, Frequency characteristics: 40 Hz - 1 kHz Basic accuracy 40 - 500 Hz : +/-1.0 % rdg. +/-3 dgt. (True RMS, crest factor 3 |
Voltage | DC- 600.0 mV to 600.0 V, 4 ranges, Basic accuracy: +/-0.5 % rdg. +/-5 dgt. |
• Achieving a high level of safety in a compact body and lightweight design
• Resistance, Capacitance measurement and diode testing (DT4222)
• Robust design capable of withstanding a drop from a height of 1 m
• Test leads conveniently wrap around the back
• ±0.5% DC V basic accuracy, wide 40 Hz to 1 kHz AC V frequency characteristics
• Low-pass filter cuts high harmonics (when measuring inverter fundamental waveforms)
• Broad -10 (14°F) to 50°C (122°F) operating temperature range • Display backlight
