ifm EVC905, Straight Male 4 way M12 to Straight Female 4 way M12 Communication Cable, 1m

Part Number : EVC905

Availability: Sold out

Detailed Description
Specifications

The ifm electronic industrial Ethernet cable is specifically designed to meet the rigorous demands of factory automation environments. Engineered for seamless connectivity and reliability, it features a sturdy moulded body crafted from high-quality TPU, ensuring longevity and resilience against harsh conditions. The cable’s exceptional performance is characterised by its ability to transmit data at speeds of 100 Mbit/s, making it ideal for various industrial applications. With its advanced shielding and gold-plated contacts, this product not only guarantees excellent signal integrity but also provides robust resistance against environmental factors. Whether it’s for static or dynamic applications, this connection cable delivers exceptional reliability and efficiency.

High protection rating for the requirements of harsh industrial environments
Cable sheath made of halogen-free and flame-retardant material
With robust M12 connector Industrial Ethernet
Large operating temperature range and high protection rating
Good

Brand	ifm
Series	EVC
Number of Cores	4
Cross Sectional Area	0.34 mm²
Length	1m
Sheath Material	Polyurethane PUR
Sheath Colour	Green
LAN Category	Cat5e
Connector 1	M12
Connector 1 Number of Contacts	4
Connector 1 Orientation	Straight
Connector 1 Gender	Male
Connector 2	M12
Connector 2 Gender	Female
Connector 2 Orientation	Straight
Connector 2 Number of Contacts	4
