ifm EVF004, Straight Female 5 way M12 to Straight Female 5 way M12 Communication Cable, 5m
The 4-pole M12 sensor cable EVF004 from ifm electronic has an angled M12 socket and a 5 m MPPE cable. Thanks to the anti-vibration protection with saw tooth contour, the M12 coupling nut made of stainless steel (1.4404) is perfectly protected against shock and vibration. The silicone-free and halogen-free EVF004 sensor cable with gold-plated contacts and protection rating IP65/IP67/IP68/IP69K is ideally suited for hygienic and wet areas in the food industry.
- Detailed Description
- Specifications
- Features
- Downloads
Permanent and reliable sealing even when mounted without tools
Cable sheath made of halogen-free and flame-retardant material
Vibration and shock resistant thanks to coupling ring with locking mech
| Brand | ifm |
| Series | EVF |
| Number of Cores | 4 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Material | Modified Polyphenylene Ether MPPE |
| Length | 5m |
| Sheath Colour | Grey |
| Connector 1 Number of Contacts | 5 |
| Connector 1 Orientation | Straight |
| Connector 1 Gender | Female |
| Connector 1 | M12 |
| Connector 2 | M12 |
| Connector 2 Gender | Female |
| Connector 2 Number of Contacts | 5 |
| Connector 2 Orientation | Straight |
- For use in sanitary and wet areas in the food industry
- Permanent, reliable sealing even when mounted without tools
- Cable jacket made of halogen-free and flame-retardant material
- Vibration and shock resistant thanks to coupling ring with locking mechanism
- Wide operating temperature range and high protection rating
