ifm IB5068, Inductive Smooth Barrel Proximity Sensor, 20 mm Detection, PNP NC, 10 → 36 V dc

Name: ifm IB5068, Inductive Smooth Barrel Proximity Sensor, 20 mm Detection, PNP NC, 10 → 36 V dc
Brand: ifm
SKU: IB5068
Availability: InStock

Part Number : IB5068

Availability: low stock

Detailed Description
Specifications
Downloads

The ifm electronic inductive sensor sets a high standard in precision and reliability for a variety of industrial applications. Designed with a robust cylindrical housing, it excels in detecting metallic objects within a sensing range of up to 20mm. The innovative design incorporates advanced features such as reverse polarity and short-circuit protection, ensuring both safety and longevity in demanding environments. With its impressive operational temperature range of -25 to 80 degrees Celsius, this sensor performs consistently, regardless of external conditions. Additionally, its IP67 protection rating ensures resilience against dust and water, making it ideal for a wide array of installations. The device's compact dimensions mean it can be easily integrated into existing systems without hassle, making it a practical choice for efficiency-driven professionals.

With PVC cable
Smooth plastic housing to protect against deposits
PBT housing resistant against pickling solutions
For applications in pickling lines
Clearly visible indication of the switching status

Brand	ifm
Sensor Technology	Inductive
Body Style	Smooth Barrel
Detection Range	20 mm
Output Function	NC
Digital Switching Output Type	PNP
Cable Length	2m
Connection Type	Pre-Cabled
Supply Voltage	10 → 36 V dc
IP Rating	IP67
Length	82mm
Mounting Type	Non-Flush
Diameter	34 mm
Switching Current	250 mA
Shielding	Unshielded
Switching Frequency	60 Hz
Series	IB5
