Mitutoyo 1044A-15 | Dial Gauge | 5 mm, 0.01 mm, lug back, 0.1-0.4 N
Part Number : 1044A-15
Mitutoyo's 1044A-15 is a Series 1 ISO type lug-back dial gauge with a 5 mm range, 0.01 mm graduation and a low 0.1-0.4 N measuring force. A jewelled bearing keeps pointer movement smooth.
- Low measuring force of 0.1-0.4 N on the 1044A-15
- 5 mm range, 0.01 mm graduation, ±0-100 dial (1044A-15)
- Repeatability 3 µm, hysteresis 3 µm (1044A-15)
- Lug back, jewelled bearing, carbide-tipped contact point
- 8 mm stem, M2.5 x 0.45 mm thread, 90 g (1044A-15)
Free UAE shipping available
For pricing, please contact our experts.
