Mitutoyo 126-131 | Screw Thread Micrometer, Interchangeable Tips | 150-175 mm, 0.01 mm, ±6 µm
Measuring 150-175 mm in 0.01 mm steps to ±6 µm, the Mitutoyo 126-131 reads screw pitch diameter directly with no calculation. For the 126-131, anvils and spindle points are bought separately and fitted as matched pairs for metric/unified or Whitworth threads.
- 150-175 mm range, 0.01 mm graduation
- Rated to ±6 µm
- Ratchet stop gives a repeatable measuring force, 126-131
- Lockable Ø6.35 mm spindle, 0.5 mm pitch on the 126-131
- Satin chrome Ø18 mm thimble, 730 g main unit
- 60° metric (unified) setting standard included for the 126-131
- Specifications
- Features
- Downloads
| Part Number | 126-131 |
| Brand | Mitutoyo |
| Type | Screw thread micrometer, interchangeable tips |
| Range | 150-175 mm |
| Graduation | 0.01 mm |
| Units | Metric |
| Measuring Force | Ratchet stop |
| Tips | Interchangeable anvils/spindle tips (optional) |
| Setting Standard | 60° metric (unified), included |
| Display | Analogue |
| Spindle | Ø6.35 mm, with lock, 0.5 mm pitch |
| Thimble | Ø18 mm, satin chrome |
| Mass | 730 g |
| Accuracy | ±6 µm |
This Screw Thread Micrometer should be used with optional, interchangeable, anvils/spindle-tips that allow you to measure a wide range of metric/unified and Whitworth screw-thread pitch diameters.
A metric (unified) 60º setting standard is included with all models except those measuring from 0.
To measure Metric/Unified or Whitworth threads, anvils and spindle points are interchangeable in matched pairs.
• Measurement of screw pitch diameter directly (no need for calculation).
• Includes a ratchet stop for accurate force measurement.
• Interchangeable anvils or spindle tips are available as an option.
