Mitutoyo 126-142 | Screw Thread Micrometer | 5-6 in, 0.001 in graduation
Covering 5-6 in with 0.001 in graduation, the Mitutoyo 126-142 is an analogue screw thread micrometer that reads pitch diameter directly, with no calculation, once a matched pair of optional anvil and spindle tips is fitted. Tips are available for metric/unified and Whitworth threads.
- Measuring range 5-6 in, read on a 0.001 in thimble scale
- Ratchet stop on the 126-142 for an even measuring force
- Spindle lock with a Ø6.35 mm spindle and 0.635 mm spindle pitch
- 60° metric (unified) setting standard supplied, since the 5-6 in range does not start at zero
- Satin-chrome thimble and sleeve, Ø18 mm; main unit 620 g
- Specifications
- Features
- Downloads
| Part Number | 126-142 |
| Brand | Mitutoyo |
| Type | Analogue screw thread micrometer |
| Range | 5-6 in |
| Graduation | 0.001 in |
| Units | Inch |
| Measuring Force | Ratchet stop |
| Tips | Interchangeable anvil/spindle tips (optional) |
| Setting Standard | 60° metric (unified), included |
| Mass (Main Unit) | 620 g |
| Measuring Spindle | Spindle lock, Ø6.35 mm, 0.635 mm pitch |
| Thimble and Sleeve | Satin chrome, Ø18 mm |
This Screw Thread Micrometer should be used with optional, interchangeable, anvils/spindle-tips that allow you to measure a wide range of metric/unified and Whitworth screw-thread pitch diameters.
A metric (unified) 60º setting standard is included with all models except those measuring from 0.
To measure Metric/Unified or Whitworth threads, anvils and spindle points are interchangeable in matched pairs.
• Measurement of screw pitch diameter directly (no need for calculation).
• Includes a ratchet stop for accurate force measurement.
• Interchangeable anvils or spindle tips are available as an option.
