Mitutoyo 2109A-11 | Flat Back Dial Gauge | 1 mm, 0.001 mm, ANSI/AGD
Part Number : 2109A-11
The Mitutoyo 2109A-11 is a flat back dial gauge with a 1 mm measuring range and 0.001 mm graduation. Built to ANSI/AGD Type 2, it is used for linear measurement and inspection, and the flat back lets it sit on flat surfaces or magnetic bases (2109A-11).
- 0-10-0 dial with 0.4 - 1.5 N measuring force
- Hysteresis 2 µm and repeatability ±0.3 µm
- 4-48 UNF thread and 9.52 mm or 0.375 in stem on the 2109A-11
- Jewelled bearing (2109A-11)
- Carbide contact point fitted to the 2109A-11
- 2109A-11: scratch-resistant, anti-glare crystal
Free UAE shipping available
For pricing, please contact our experts.
