Mitutoyo 2902AB-01 | Dial Indicator | 10 mm Range, 0.01 mm Graduation, Flat Back
Part Number : 2902AB-01
Mitutoyo's 2902AB-01 dial indicator covers 10 mm with a 0.01 mm graduation. The 2902AB-01 is intended for precise linear measurement, quality control and inspection.
- Conforms to ANSI/AGD type, flat back for flush mounting; 100-0 dial graduations
- 3 µm hysteresis and ±3 µm repeatability; 9.52 mm (0.375 in) stem; carbide-tipped contact point with 4-48 UNF thread
- 0.4–1.4 N measuring force
- Analogue dial readout; graduated in 0.01 mm steps
- Measuring range of 10 mm
Free UAE shipping available
For pricing, please contact our experts.
