Mitutoyo 293-180-40 QuantuMike Digital Micrometer, Range 0 ~ 1″/25.4mm
The 293-180-40 Digimatic Micrometer's high speed and precision greatly cut down on the amount of time needed to approach and release the workpiece.
High Accuracy & Speed: It moves the spindle four times quicker than conventional metric micrometers. This allows for faster movement and superior accuracy with a maximum allowable error (J MPE) of only ± 1 μm, allowing for more efficient measuring work.
- Specifications
| Range | 0 ~ 1″/25.4mm |
| Resolution | 0.00005"/0.001mm |
| Accuracy | ±0.00005" |
| Flatness | 0.000012" |
| Parallelism | 0.00004" |
| Display | LCD, character height 7.5mm |
| Measuring Face | Carbide-tipped, micro-lap finish |
| Measuring Spindle | With spindle lock, ø6.35mm, spindle pitch 2mm |
| Measuring Force | 7 ~ 12N |
| Power Supply | 1 battery CR2032 |
| ON/OFF | Yes |
| ABS/INC (INC ZERO) | Yes |
| Auto Power OFF after 20 min | Yes |
| Low Voltage Alarm | Yes |
| Function Lock | Yes |
| HOLD | Yes |
| PRESET | Yes |
| Mass | 265g |
