Mitutoyo 293-351-10 | Coolant Proof Micrometer | Series 293 | Accuracy ±.0001 inch | Range 5 inch to 6 inch
The Mitutoyo 293-351-10 Coolant Proof Micrometer from Series 293 is designed for high-precision measurements in environments where coolant and fluids are present. It has a range of 5 inches to 6 inches and offers an accuracy of ±0.0001 inch, ensuring exceptional precision. The micrometer is built with a special coolant-proof construction, making it resistant to damage from oils, water, and other cutting fluids commonly used in machining processes. This makes it ideal for use in workshops and manufacturing settings. The robust design ensures reliable performance even in harsh environments.

Free UAE shipping available
- Specifications
- Features
- Downloads
Accuracy | +/-0.0001 inch |
Alarm | Low voltage, Counting value composition error |
Battery Life | Approx. 1.2 years |
Battery | SR44 |
Data hold function | Yes |
Data Output | Yes |
Display | LCD |
Flatness | 0.31/4m |
ON/OFF | Automatic |
Protection | IP65 |
Range | 5 inch to 6 inch |
Resolution | 0.001mm, .00005"/0.001mm |
Type | Coolant Proof Micrometer |
- Use in areas subjected to cutting oil, etc., is made possible by the IP65 protection level.
- A water-resistant connection cable is supplied for the measurement data output function.
- Every plastic component is made of materials that are resistant to oil.
- ±1pm instrumental error (models with a range of 75mm/3" or less)
- automatic ON/OFF power switch.
- Included is the Certificate of Inspection. (Models with a range of 50mm/2" or less)
