Mitutoyo 314-351-30 | 3-Flute V-Anvil Digital Micrometer | 0.05-0.6 in, with groove
Part Number : 314-351-30
The Mitutoyo 314-351-30 is a Digimatic V-anvil micrometer for three-flute cutting tools from 0.05-0.6 in. It checks the outside diameter of taps, reamers and end mills on a 60° prism anvil. On this 0.05-0.6 in size, the V-anvil has a centreline groove for measuring tap pitch diameter by the single-wire method.
- Range 0.05-0.6 in for 3-flute tools
- Centreline groove for single-wire tap pitch diameter
- Digital step 0.00005 in; mass 275 g
- Prism angle 60°; spindle lock; 6.35 mm spindle, 0.75 mm pitch
- Data output and ZERO/ABS; about 2.4 years on one battery
- Supplied with box, setting standard, key and battery
For pricing, please contact our experts.
