Mitutoyo 3803AB-10 | Flat Back Dial Indicator | 0.0001 in grad, 0.025 in range
Part Number : 3803AB-10
The Mitutoyo 3803AB-10 is a flat back Series 3 dial indicator made to the ANSI/AGD standard, with 0.0001 in graduations across a 0.025 in range. Mounting of the 3803AB-10 is by its flat back, while jewelled bearings keep the movement smooth.
- 3803AB-10 dial reading: 0-5-0
- Repeatability ±0.00003 in, hysteresis 0.0001 in (3803AB-10)
- Measuring force 0.4–2 N on the 3803AB-10
- Carbide-tipped contact point with 4-48UNF thread on the 3803AB-10
- 3803AB-10 stem diameter 9.52 mm or 0.375 in; main unit mass 245 g
