Mitutoyo 543-311B-10 | Digital Indicator | Bore Gauge ID-C | Series 543 | Resolution 0.00005 inch | Accuracy 0.0001 inch | Range 0.5 inch

Client Production

Dedicated Support

Genuine Products

Client Production

Dedicated Support

Genuine Products

Part Number : 543-311B-10

The Mitutoyo 543-311B-10 Digital Indicator from Series 543 is a bore gauge-type ID-C model, purpose-built for precision internal measurements. With an ultra-fine resolution of 0.00005 inch and high accuracy of ±0.0001 inch, it ensures extremely precise and repeatable results. The 0.5-inch measuring range makes it ideal for small to medium bore applications. Designed for use in both industrial and laboratory environments, this indicator is compact, easy to operate, and highly dependable for critical dimensional inspections.

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Alarm	Low voltage, ABS composition error, overflow error, setting error
Analog/Digital	Digital
Battery Life	Standard mode: approx. 1 year, Fast mode: approx. 4.5 month
Contact point	Carbide Ball
Data hold function	Yes
Digimatic data output	Yes
Digital step	0.00005 in/0.0001 in/0.0005 in or 0.001 mm/0.01 mm
Display	LCD, character height 8 mm, 330° rotatable
GO/+/-NG judgement	Yes
Hysteresis	0.0001 Inch or 0.002 mm
Inch-Metric	Inch/Metric
Lock function	Yes
Max. permissible error	E MPE : +/-0.0001 Inch or 0.003 mm
Max. Response Speed	Unlimited
Measuring Force	¢°¤1.5 N
Model Number	ID-C112GMXB2
ON/OFF	Yes
Power Supply	1 battery CR2032
Protection	IP42
Range	0.5 Inch or 12.7 mm
Repeatability	0.0001 Inch or 0.002 mm
Scale	Electrostatic capacitance type absolute linear encoder
Series	543
Stem Dia	8 mm
Thread type	M2.5x0.45
Type	Digital Indicator
Type	EN ISO Standard
Weight	170 g

Bore Gauge Type: Specially designed for accurate internal diameter measurement.
Ultra-Fine Resolution: 0.00005-inch resolution for detailed and exact readings.
High Accuracy: ±0.0001 inch accuracy for reliable measurement performance.
Compact Measuring Range: 0.5-inch range ideal for smaller bore applications.
Precision Engineering: Built for use in high-accuracy environments like QC labs and production lines.
Durable and User-Friendly: Engineered for long-term use with easy integration into bore gauge setups.

DOWNLOAD CATALOG
