Mitutoyo 810-404-11-BSET1 | Semi Automatic Micro Vickers Hardness Testing Machine | HM-210 B-Type Set | One Indentershaft Operation Temperature 5 to 40°C | Vibration Frequency 5Hz or lower | Mass 40 kg

Name: Mitutoyo 810-404-11-BSET1 | Semi Automatic Micro Vickers Hardness Testing Machine | HM-210 B-Type Set | One Indentershaft Operation Temperature 5 to 40°C | Vibration Frequency 5Hz or lower | Mass 40 kg
Brand: Mitutoyo
SKU: 810-404-11-BSET1
Availability: InStock

Part Number : 810-404-11-BSET1

The Mitutoyo 810-404-11-BSET1 HM-210 B-Type Set is a semi-automatic Micro Vickers hardness testing machine designed for precise hardness measurements on small or thin materials. It operates effectively within a temperature range of 5°C to 40°C and is suitable for environments with vibration frequencies of 5 Hz or lower. Weighing 40 kg, it offers stability during testing. This model is ideal for applications requiring accurate microhardness testing, such as in materials science research, quality control in manufacturing, and failure analysis.

Availability: low stock

Free UAE shipping available

Specifications
Features
Downloads

Dimensions	External dimensions WxDxH : 315x586x683 mm
Light Source	Light source illumination unit : White LED
Mass (main unit)	40 kg
Operation temperature	5-40
Optical system	Infinitely corrected
POWER CONSUMPTION	30
Power Supply	AC100 -240V Auto-selection
Relative Humidity	80% or lower without condensation
Series	810
Standard	Standard objective lenses : MH Plan 10x and 50x
Type	Semi Automatic Micro Vickers Hardness Testing Machine
Vibration	5Hz or lower

Semi-Automatic Operation: Offers precise control over test force application, suitable for expert users needing flexibility.
Wide Load Range Compatibility: Supports a range of test forces (10 gf to 1000 gf), allowing versatility in testing various materials.
Stable and Robust Construction: Weighing 40 kg, it ensures vibration resistance and stable operation during sensitive measurements.
Optical System with Fine Resolution: Includes high-quality optics for clear indentation visibility and accurate diagonal length measurement.
Data Output Compatibility: Allows integration with optional accessories for data capture and analysis (e.g., micrometers, analyzers).
