Mitutoyo 810-443-11-DSET | Fully Automatic Vickers Hardness Testing Machine | HV-110 D-Type Set | Operation Temperature 5 to 40°C | Vibration Frequency 10Hz or Lower | Mass 73.9 kg
The Mitutoyo 810-443-11-DSET is a fully automatic Vickers Hardness Testing Machine featuring the HV-110 D-Type Set, designed for high-precision material testing. The fully automated system enhances accuracy and consistency, streamlining the testing process and improving efficiency in both lab and industrial settings. It operates reliably within a temperature range of 5°C to 40°C, ensuring stable performance in typical environmental conditions. The machine is engineered to perform accurately in environments with vibration frequencies of 10Hz or lower, reducing external interference. With a mass of 73.9 kg, it provides a stable and vibration-resistant base, ensuring dependable results. This machine is ideal for high-volume testing, research, and quality control applications requiring consistent and precise hardness measurements.

Free UAE shipping available
- Specifications
- Features
- Downloads
Control Type | AVPAK software control |
Control Type | Turret: Touch panel |
Data Output | PDF, Excel |
Dimensions (Wƒ-Dƒ-H) | 382x627x874 mm |
Drive method | Turret: Motor/Manual |
Height | Specimen: 132 mm |
Indenters | Approach Speed: selectable 60 1/4m/s/150µm/s |
Light Source | White LED |
Mass (main unit) | 73.9 kg |
Objective Zoom | MH Plan 2x, 10x and 20x |
Operation temperature | 5-40°C |
Optical system | Infinitely corrected |
Port | Indenter: 1 (equipped) |
Port | Objective Lens: 3 (3 equipped) |
POWER CONSUMPTION | 89 W |
Power Supply | AC100 -240V Auto-selection |
Range | Test Force: 2.942-294.2N (0.3-30kgf) |
Range | XY: 100x100 mm |
Range | Z-axis: 1.4 mm |
Relative Humidity | 80% or lower without condensation |
Resolution | 0.01 HV units (settable) |
Standards | Vickers: ISO 6507-2, ASTM E92, ASTM E384, JIS B 7725 |
Switch Type | Test Force: AVPAK software |
Test force duration | 5-999s. 1 s. increments |
Throat Depth | 170 mm |
Type | Fully automatic Vickers Hardness Testing Machine |
Vibration | 10Hz or lower |
WATER VOLUME | 11AAB941 |
Weight | Specimen: 3 kg |
XY Stage Size | 810-462-10 |
- Fully Automatic Operation: Automates the entire hardness testing process, improving consistency and efficiency.
- HV-110 D-Type Set: Includes essential components for comprehensive and precise hardness testing.
- Wide Operating Temperature Range: Functions effectively in environments with temperatures between 5°C and 40°C.
- Low Vibration Sensitivity: Designed to work accurately in areas with vibration frequencies of 10Hz or lower.
- Stable and Robust Construction: Weighs 73.9 kg, offering a vibration-resistant and stable platform for testing.
- Ideal for High-Volume Testing: Perfect for research, quality control, and industrial applications that require fast, reliable results.
