Mitutoyo 926-220 | Cylindrical Measuring Pin Set | 91 Pcs, Grade 1, DIN 2269
Mitutoyo 926-220: a 91-piece Grade 1 cylindrical measuring pin set (DIN 2269) for hole and internal dimension checks, with pins hardened to HRC 60-62 and a 3 kg total mass.
- 91 pins, Grade 1, diameter error limit ±1 µm
- Pin length 50 mm up to ø6 mm, 70 mm above ø6 mm
- Hardness HRC 60-62
- Very fine ground; sizes inscribed from ø3 mm
- Surface roughness Ra ≤ 0.1 µm; set mass 3 kg
- Specifications
- Features
- Downloads
| Part Number | 926-220 |
| Brand | Mitutoyo |
| Series | 926 |
| Type | Cylindrical measuring pin set, DIN 2269 |
| Length | 50 mm (≤ ø6 mm), 70 mm (> ø6 mm) |
| Finish | Very fine ground, inscribed from ø3 mm |
| Hardness | HRC 60-62 |
| Mass | 3 kg (6.61 lb) |
| Pieces | 91 |
| Grade | 1 |
| Diameter Error Limit | ±1 µm |
| Roughness | Ra ≤ 0.1 µm |
- High Precision: The pins are manufactured to Grade 1 accuracy, ensuring reliable and accurate measurements for internal dimensions.
- Durable Material: Made from hardened steel with a hardness range of HRC 60 to 62, providing excellent wear resistance and longevity.
- Comprehensive Set: Includes 91 pieces of incremental-sized measuring pins, allowing for a wide range of measurements for various hole sizes.
- DIN 2269 Compliance: Meets the DIN 2269 standard, ensuring conformity to international measurement specifications.
- Compact and Heavy Duty: With a total mass of 3 kg, the set is robust and portable for use in precision measurement applications in industrial environments.
